212 E8257D/67D, E8663D PSG Signal Generators Service Guide
Replaceable Parts
Cables
W53
(E8267D)
Front Panel (SYMBOL SYNC) A31J502 8121-0628
W54 A9J9 A31J1032 8121-0624
W55 A10J304 Rear Panel
(SOURCE MOD INTERFACE)
8121-0636
W56
(E8267D)
A13J14 Rear Panel (-Q OUT) 8121-0901
W57
(E8267D)
A13J13 Rear Panel (-I OUT) 8121-0901
W58
(E8267D)
A13J12 Rear Panel (Q OUT) 8121-0901
W59
(E8267D)
A13J11 Rear Panel (I OUT) 8121-0901
W60
(Std. E8267D or
with Option 015)
A13J10 A31J1052 8121-0626
W61
(Std. E8267D or
with Option 015)
A13J9 A31J1053 8121-0626
W62
(E8267D)
A13J6 A35J7 8121-0624
W63
(E8267D)
A13J5 A35J6 8121-0624
W64
(E8267D)
A14J13 A17P2 8121-0920
W65
(E8267D)
A14J800 Rear Panel
(BASEBAND GEN REF IN)
8121-0901
W66
(E8267D)
A18P2 A34 Internal Hard Drive 8121-0685
W67
(E8267D)
Semi-Rigid Cable, A31 Motherboard Rear Panel
(.25-3.5 GHz COH CARRIER)
E8251-20223
W68
(E8267D)
A17P4 A31J250 8121-0925
W69 A26J14 A12 Pulse Modulator Board 8121-0912
W70
(E8267D)
A26J34 A35 I/Q MOD 8121-0615
Table 2-4 (Continued)
Reference Designator Input Output Part Number
