E8257D/67D, E8663D PSG Signal Generators Service Guide 199

Replaceable Parts

Assemblies from a Top View

Figure 2-4 Assemblies from a Top View (E8257D Option 521)

A10

A11

A19

A32

(Option UNX/UNY)

A18

A40

AT1

(Option 1E1)

A25

A24

A23

A26

A25B

A43

A33

A20

A41

(under

A40)

(A46)

(Option UNY)

(A45)

(Option UNY)
