E8257D/67D, E8663D PSG Signal Generators Service Guide 201

Replaceable Parts

Assemblies from a Top View

Figure 2-6 Assemblies from a Top View (E8267D Option 513/520)

A32

(Option UNR/UNX/UNY)

A20 B1A40

A19

A13

A14

A18

A25B

A25

A24

A33

A26

AT1A11 A8 A7A9A10 A6 A5

(instruments with serial

prefixes >

US4805/MY4805)

p_dig_top

A41

A23A38

(A45)

(A46)

(Option UNY)
