286 E8257D/67D, E8663D PSG Signal Generators Service Guide

Assembly Replacement

A11 Pulse/Analog Modulation Generator

Figure 3-17 A11 Pulse/Analog Modulation Generator

W16/A11J204

W6/A11J203

W7/A11J202

W17/A11J205

W5/A11J201

W1/A11J401

W2/A11J402

W3/A11J403

A11

W96/A11J206
