290 E8257D/67D, E8663D PSG Signal Generators Service Guide

Assembly Replacement

A13 I/Q MUX (E8267D Standard or with Option 015) (Serial Prefixes

<US4722/MY4722)

2. Perform the post–repair adjustments and performance tests that pertain

to this removal procedure.

Figure 3-19 A13 I/Q MUX (E8267D Standard or with Option 015) (Serial Prefixes

<US4722/MY4722)

W58/A13J12

W59/A13J11

W63/A13J5

W62/A13J6

W61/A13J9

W49/A13J7

W57/A13J13

W60/A13J10

W50/A13J8

W56/A13J14
