E8257D/67D, E8663D PSG Signal Generators Service Guide 303

Assembly Replacement

A19 Power Supply

Figure 3-25 A19 Power Supply Removal

A22W1

A22W2

W18/A18J1

W66/A18J2

W20

W64/A14J13

A19
