E8257D/67D, E8663D PSG Signal Generators Service Guide 311

Assembly Replacement

A23 Lowband Coupler/Detector

3. Torque all RF connectors to 8 in–lbs.

4. Perform the post–repair adjustments and performance tests that pertain

to this removal procedure.

Figure 3-29 A23 Lowband Coupler/Detector

E8257D & E8663D – W37

A23

E8267D – W75
