314
E8257D/67D, E8663D PSG Sign
al Generators Servic
e Guide
Assembly Replacement
A24 20 GHz Highband Coupler (Options
503, 509, 513, 520, and 521)
Figur
e
3-31
A24 20 GHz Highband Coupler
(Options 503, 509, 513, and 520 – Option
1EM)
A24
A25B
A33
A25
W72
W71
303
305
