318 E8257D/67D, E8663D PSG Signal Generators Service Guide

Assembly Replacement

A24 40 GHz Highband Coupler (Option 540)

Figure 3-34 A24 40 GHz Highband Coupler (Option 540 – Standard)

Figure 3-35 A24 40 GHz Highband Coupler (Option 540 – Option 1EM)

A25BW1

W30

W24

A24

A25

A24

W71

W72

A25B

A25BW1

A25
