320 E8257D/67D, E8663D PSG Signal Generators Service Guide

Assembly Replacement

A24 50 GHz Highband Coupler (Options 532 and 544)

Figure 3-36 A24 50 GHz Highband Coupler (Options 532 & 544 – Standard)

Figure 3-37 A24 50 GHz Highband Coupler (Options 532 & 544 – Option 1EM)

A25

A33

A25B

A24

W102

W24

W93

A25B

A24

A25 & A33

W102

Default Chapter5
