324
E8257D/67D, E8663D PSG Sign
al Generators Servic
e Guide
Assembly Replacement
A25 20 GHz Highband Detector (Options 503, 509, 513
, 520, & 521)
Figur
e
3-40
A25 20 GHz Highband Detect
or (Options 503, 509, 513, and 520)
A25
A33
313
315
