338 E8257D/67D, E8663D PSG Signal Generators Service Guide

Assembly Replacement

A27 40 GHz Doubler (Option 540)

Figure 3-48 A27 40 GHz Doubler (Option 540)

W29

W32

W31

A27

Option 1EM – W83

Standard – W30
