344 E8257D/67D, E8663D PSG Signal Generators Service Guide

Assembly Replacement

A29 20 GHz Doubler

Figure 3-51 A29 20 GHz Doubler

E8257D & E8663D – W38/A29J1

W39/A29J4

A29

E8257D & E8663D – W41/A29J2

W33/A29J10

E8267D – W77/A29J2

W40

E8267D – W115/A29J1
