E8257D/67D, E8663D PSG Signal Generators Service Guide 347

Assembly Replacement

A30 Modulation Filter (Standard and Option 1EA/1EU)

Figure 3-52 A30 Modulator Filter

W34/A30J10

W27/A30J3

W106 (Option 550/567)

W17/A30J7

W108/A30J6

E8257D & E663D– W41/A30J1

E8267D – W98/A30J1

A31

A35

E8257D & E8663D – W74 (Options 503/509/513/520/521), W31 (Option 540), W107 (Option 550/567), W71 (Option 1EM)

E8267D – W74 (Option 513/520), W103/A30J2, W71 (Option 1EM)

W32 (Options 503/509/513/520/532/540)
