E8257D/67D, E8663D PSG Signal Generators Service Guide 353

Assembly Replacement

A31 Motherboard (E8267D)

Figure 3-54 A31 Motherboard (E8267D)

W23

W76

W39

W60/A31J1052

W61/A31J1053

W11/A31J1021

W21/A31J1043

W10/A31J1031

W22/A31J1042

W47/A31J1041

W54/A31J1032

W53/A31J502

W51/A31J500

W67

W68/A31J250

W52/A31J501

Default Chapter5
