370 E8257D/67D, E8663D PSG Signal Generators Service Guide

Assembly Replacement

A35 3–20 GHz I/Q Modulator (E8267D Only - Standard or with Option 015)

— Torque all T–10 screws to 9 in–lbs.

— Torque all RF connectors to 8 in–lbs.

— Perform the post–repair adjustments and performance tests that pertain to

this removal procedure.

Figure 3-61 A35 3–20 GHz I/Q MOD

W63/A35J6

W80/A35J106

W62/A35J7

W97/A35J8

A35

W79/A35J9

W77/A35J1

W104/A35J3

W78

W70

W105/A35J4

Default Chapter5
