372 E8257D/67D, E8663D PSG Signal Generators Service Guide

Assembly Replacement

A35 3–20 GHz I/Q Modulator (E8267D Only - Standard or with Option H16/016) (Serial

Prefixes ≥ US4722/MY4722)

— Torque all RF connectors to 8 in–lbs.

— Perform the post–repair adjustments and performance tests that pertain to

this removal procedure.

Figure 3-62 A35 3–20 GHz I/Q MOD (E8267D only - Standard or with Option 016)

(Serial Prefixes ≥ US4722/MY4722)

W63/A35J6

W62/A35J7

A35

W128/A35J107

W129/A35J108

W130/A35J106

W127/A35J109

W134

W77/A35J1
