374 E8257D/67D, E8663D PSG Signal Generators Service Guide

Assembly Replacement

A36 Quadraplier (Options 550 and 567)

Figure 3-63 A36 Quadraplier

W110/A36J6

W96/A36J5

W112/RF OUT

W113/A36J10

W106/A36J1

W107/A36J2

W111/A36J7

W108/A36J4

W109/A36J3
