390 E8257D/67D, E8663D PSG Signal Generators Service Guide

Assembly Replacement

A44 Scan Modulation Bias Adapter (E8257D-520 and E8663D Only)

Figure 3-72 A44 Scan Modulation Bias Adapter

A44J3

A44J5

A44J2

A44 (Scan Modulation

A44J1

Bias adapter)

Default Chapter5
