50 E8257D/67D, E8663D PSG Signal Generators Service Guide

Troubleshooting

Troubleshooting Assembly–Level Problems

Figure 1-4 E8257D Motherboard Power Supply LEDs

DS101

DS103

DS104

DS112

DS113

DS102

DS109

DS100

DS110

DS111

DS106

DS105

+9V

+8V

–6V

–5.2V

+5.2VDF

+3.4VD

+15VSTBY

+32V +15V

+10V

–7V

–15V

+5.2V

DS107
