Environmental Characteristics
Environment Indoor use only
Ambient Temperature Operating: +5 °C to +40 °C
Non-operating: –40 °C to +70 °C
CAUTION: If storing the oscilloscope above +40 °C, make sure the flip-out
front feet are retracted.
Humidity Operating: maximum relative humidity 80 percent for temperatures up to
31 °C, decreasing linearly to 50 percent relative humidity at 40 °C
Non-operating: up to 95 percent relative humidity, non-condensing, at
40 °C; decreasing linearly to 50 percent relative humidity at 70 °C
Altitude Operating: up to 3,000 meters (9,842 feet)
Non-operating: up to 15,300 meters (50,000 feet)
Weight 32 lbs (14.5 kg)
Dimensions Height = 328 mm (12.91 in, with flip-out front feet and handle retracted)
Width = 445 mm (17.52 in)
Depth = 224 mm (8.82 in, including knobs and rear feet)
Safety UL 61010-1:2010/CAN/CSA C22.2 No. 61010-1-12
IEC 61010-1:2017
IEC 61010-2-030:2017
UL 61010-2-030:2018
CAN/CSA-22.2 No. 61010-2-030-17
Installation Category II
Voltage Fluctuations Note that the mains supply voltage fluctuations are not to exceed ±10% of
the nominal supply voltage. Temporary overvoltages may not exceed the
allowed voltage fluctuations of +10% nominal.
Pollution Degree The Infiniium MXR-Series real-time oscilloscopes may be operated in
environments of Pollution Degree 2.
Pollution Degree
Definitions
Pollution Degree 1: No pollution or only dry, non-conductive pollution
occurs. The pollution has no influence. Example: A clean room or
climate-controlled office environment.
Pollution Degree 2. Normally only dry non-conductive pollution occurs.
Occasionally a temporary conductivity caused by condensation may occur.
Example: General indoor environment.
Pollution Degree 3: Conductive pollution occurs, or dry, non-conductive
pollution occurs which becomes conductive due to condensation which is
expected. Example: Sheltered outdoor environment.
