32 Keysight Infiniium MXR-Series Real-Time Oscilloscopes User's Guide
2 Getting Started
Default Setup and Autoscale
With the setup and display controls you can quickly get a stable waveform display,
clear the display, and set the oscilloscope to a known starting condition.
Using Default Setup
To reset the oscilloscope to its default setup, press [Default Setup]. You can use the
Undo button to undo a default setup.
Using Autoscale
To automatically configure the oscilloscope to best display the current input
signal(s), press [Auto Scale] or choose Control > Autoscale.
Figure 11 [Auto Scale] and [Default Setup] keys
Save the Current Oscilloscope Configuration
Before using the default setup, you may want to save the current oscilloscope configuration
for later use. See the online help for instructions on saving setups, and for information on the
exact configuration that is set when you use the default setup. See "Accessing the Online
Help" on page 51.
