1 Setting Up
Positioning for Proper Airflow
Position the oscilloscope where it will have sufficient clearance for airflow around
the back and sides.
Figure 1 Positioning the MXR-Series oscilloscope with sufficient clearance
Front view
Minimum 0 mm
Minimum 25.4 mm
Minimum bottom clearance:
No intrusion into the space
under the oscilloscope as
defined by the feet. Feet must
rest on hard surface.
Top view
Minimum 0 mm
Minimum 25.4 mm
Rear panel
Minimum 75 mm
