46 Keysight Infiniium MXR-Series Real-Time Oscilloscopes User's Guide
2 Getting Started
Making Measurements
To make a measurement, either drag a measurement icon to the waveform event
you want to measure, or click a measurement icon and use the resulting dialog box
to specify which source you want to measure.
For measurements on waveform features, such as those that involve waveform
edges, if you click the measurement icon and specify a source, the measurement
defaults to using the feature closest to the horizontal reference point. If you make
the measurement using drag and drop, the measurement uses the waveform
feature closest to the point where you drop the icon.
The most commonly used measurements are available in the drag-and-drop area.
Others are available from the Add Measurement dialog box (Measure/Mark > Add
Measurement...).
Figure 21 Drag-and-drop measurements
Expand and collapse
the measurement icons
Drag and drop
measurement icons
showing most commonly
used measurements
