Testing Performance 6
Keysight Infiniium MXR-Series Real-Time Oscilloscopes User's Guide 69
Offset Accuracy Test
Specifications
Equipment
Required
Procedure
1 Disconnect all cables from the oscilloscope channel inputs.
2 Click Control > Factory Default. The input impedance for channel 1 should be
50 Ω.
3 Click Setup > Acquisition.... In the Acquisition dialog box, enable averaging and
set # of Averages to 256.
Ensure that the input voltage to the oscilloscope never exceeds ±5 V.
The oscilloscope must be warmed up (with the oscilloscope application running) for at least
30 minutes at ambient temperature prior to the start of any performance test.
Offset Accuracy ±0.1 div ±2 mV ±1.0% of offset setting for offsets < 2V
±0.1 div ±2 mV ±1.5% of offset setting for offsets ≥ 2V
50 Ω Input Impedance: Full scale is defined as 8 vertical divisions. Magnification is used below
2 mV/div. Below 2 mV full scale is defined as 16 mV. The major scale settings are 5 mV, 10 mV,
20 mV, 50 mV, 100 mV, 200 mV, 500 mV and 1 V.
1MΩ Input Impedance: Full scale is defined as 8 vertical divisions. The major scale settings are
5 mV, 10 mV, 20 mV, 50 mV, 100 mV, 200 mV, 500 mV, 1 V, 2 V, and 5 V.
Description Critical specifications Recommended model
or part number
Digital Multimeter DC voltage measurement accuracy better than
±0.1% of reading
34411A, 3458A, or
34465A
Cable Assembly (2
required)
50 Ω characteristic impedance, BNC (m)
connectors
8120-1840
DC Power Supply 100V 6614C
Adapter BNC Tee (m)(f)(f) 1250-0781
Adapters (2) BNC (f) to dual banana (m) 1251-2277
