70 Keysight Infiniium MXR-Series Real-Time Oscilloscopes User's Guide
6 Testing Performance
4 Configure the oscilloscope to measure the average voltage (V avg) on channel
1 as follows:
a Change the vertical scale of channel 1 to 5 mV/div.
b Click the Vertical Meas tab on the left side of the screen, then drag and drop
the Average measurement icon onto the channel 1 waveform.
