Setting Up 1
Keysight Infiniium MXR-Series Real-Time Oscilloscopes User's Guide 17
Connecting Power to the Oscilloscope
Connect the power cord to the side of the oscilloscope, then to a suitable AC
voltage source. Route the power cord so the oscilloscope's feet do not pinch the
cord.
The power cord is the disconnecting device for Mains. Position the equipment so
the power cord is easily reached by the operator.
Table 2 Power requirements
Power 100-120 V, 50/60/400 Hz
100-240 V, 50/60 Hz
650 W MAX on 8-channel models
450 W MAX on 4-channel models
Use only the power cord that came with the oscilloscope
The power cord provided is matched to the country of origin of the order.
To avoid electric shock, be sure the oscilloscope is properly grounded.
