Keysight Technologies IntegraVision PA2200 Series User Manual

Group Measurements - Delta-Wye and Wye-Delta
The following Delta-Wye and Wye-Delta measurements are available for wiring groups, as
shown below.
Measurement 1P-3W-2M 3P-3W-2M 3P-3W-3M 3P-4W-3M
Delta-Wye, Wye-Delta
Differential Voltage (AC+DC)
•
Differential Voltage (AC)
•
Differential Voltage (DC)
•
Differential Current (AC+DC)
•
Neutral Current (AC+DC)
• • •
Neutral Current (AC)
•
Neutral Current (DC)
•
Unmeasured Voltage (AC+DC)
•
Unmeasured Current (AC+DC)
•
Delta-Wye Voltage L1 (AC+DC)
• •
Delta-Wye Voltage L2 (AC+DC)
• •
Delta-Wye Voltage L3 (AC+DC)
• •
Delta-Wye Power L1 (AC+DC)
• •
Delta-Wye Power L2 (AC+DC)
• •
Delta-Wye Power L3 (AC+DC)
• •
Delta-Wye Apparent Power L1 (AC+DC)
• •
Delta-Wye Apparent Power L2 (AC+DC)
• •
Delta-Wye Apparent Power L3 (AC+DC)
• •
Delta-Wye Reactive Power L1 (AC+DC)
• •
Delta-Wye Reactive Power L2 (AC+DC)
• •
Delta-Wye Reactive Power L3 (AC+DC)
• •
Wye-Delta Voltage L1 > L2 (AC+DC)
•
Wye-Delta Voltage L2 > L3 (AC+DC)
•
Wye-Delta Voltage L3 > L1 (AC+DC)
•
Keysight IntegraVision PA2200 Series Power Analyzers Operating and Service Guide117
