Phasor Diagram
The instrument's phasor diagram can show various measurements and phase relationships.
Displaying the phasor diagram
On the PA2203A, press the [Phasor] key (between channels 3 and 4 on the front panel) to
display the phasor diagram.
On the PA2201A or the PA2203A, you can press [Display] > Phasor, or you can use the blue
menu symbol in the upper left corner of the display.
Keysight IntegraVision PA2200 Series Power Analyzers Operating and Service Guide71
