Learn the Front Panel
1 The color display (800x600 pixels) is the
heart of the power analyzer's user inter-
face.
2 Configure the horizontal axis and navigate
through the waveform.
Horizontal Controls
Keysight IntegraVision PA2200 Series Power Analyzers Operating and Service Guide21
