To add an annotation
You can add annotations to the display for documentary purposes before capturing screens.
1. Press [Label]>Annotation.
2. In the Annotation Menu, press Annotation to enable the annotation. Then use the
touchscreen to drag the annotation as desired.
3. Press Edit and enter text using the touch screen or the Entry knob.
4. Select the dialog's Enter or OK key again. The annotation text appears in the softkey as
shown below.
5. Press TextColor and select the annotation color. You can choose white, red, or colors that
match channels 1 and 2, math waveforms, or reference waveforms.
6. Press Background and select the annotation background (opaque or inverted).
See Also
Saving Setups, Screen Images, or Data
Print (Screens)
70 Keysight IntegraVision PA2200 Series Power Analyzers Operating and Service Guide
