Functions and Measurements
Files Operation
96
Saving a File
The anlyzer allows you to save files (states, traces, limits or
screens) to a USB storage device (USB/), or internal storage
(INT/). The following is an example of how to save a trace to
internal storage (INT/).
1 Select the save destination for the file. This example will
select the internal storage (INT/):
Press File > Directory > Memory Type INT
2 Press Return > Save as, the pop- up window displays for your
further setting.
3 Edit a file name.
A file name can consist of letters and digits. A single key
stroke on the numerical keypad inputs a digital number; and
consecutive key stroke selects and inputs a letter.
4 Rotate the knob to choose the file type you need.
5 Press Enter to save the file. The file will be saved
immediately and “File saved” will be shown in the status bar.
Quick Saving a File
Press [Save] to quickly save a trace or a screen to either the
local memory or an external USB device, depending upon
the setup of the save path.
Refer to the steps for saving a trace/screen:
1 Press File > Setup > Qsave Type to set the quick save file type.
2 Press File > Directory > Media Type to select the file directory.
3 Press Return > Save to save a trace or a screen copy to the
pre- defined memory. The trace or screen will be
automatically assigned with a default file name. A trace will
be assigned with a file name, such as HYTRACE,
CAUTION
When saving a file to a USB storage device, do not disconnect the
USB device during the save operation. To do so may cause unexpected
data loss.
