Functions and Measurements
Making a Basic Measurement
Viewing a Signal
Refer to the procedures below to view a signal.
1 Press System > Pow on/off Preset > Preset Type > Factory to enable
the factory- defined preset state.
2 Press Preset to restore the analyzer to its factory- defined
state.
3 Connect the 10 MHz REF OUT on the rear panel to the
front- panel RF IN.
Setting the Reference Level and Center Frequency
1 Press Amplitude > 10 > dBm to set 10 dBm reference level.
2 Press Frequency > 30 > MHz to set 30 MHz to center frequency.
Setting Frequency Span
Press Span > 50 > MHz to set 50 MHz frequency span.
Reading Frequency and Amplitude
1 Press Peak Search to place a marker (labeled 1) on the
10 MHz peak.
NOTE
Changing the reference level changes the amplitude value of the top
graticule line. Changing the center frequency changes the horizontal
placement of the signal on the display. Increasing the span will
increase the frequency range that appears horizontally across the
display.
