Functions and Measurements
Making a Basic Measurement
32
2 Press System > Pwr on/off Preset > Save User, to save the
current instrument settings as the ‘user preset’ state. The
user preset will not affect the default factory preset settings.
User preset settings can be changed and saved at any time.
Figure 3-1 Factory Default Preset Setting
Attenuation 20 dB(Auto) Average Type Log Pwr
Center frequency 3.5 GHz Average Number 100 (Off)
Reference offset 0 dB Peak Excursion 6 dB
Start Frequency 0 Hz Peak Threshold -140 dBm
Stop Frequency 7 GHz Peak Search Type Max
Hi-Sensitivity Off Continuous Pk Off
Span 7 GHz Graticule On
Reference level 0 dBm Y Scale On
Log scale/Division 10 dB Cal Out Off
Int Preamp Off Probe Power Off
Trace 1 Clear Write Trig ge r Free Run
Trace 2, 3, 4 Blank Marker Mode Normal
Sweep Time 328.5 ms(Auto) Marker Function Normal
Sweep Continuous Marker Table Off
Limit Line Off Measure Meas Off
Limit Off File Catalog Int
Impedance 50 Ω File Sort By Date
Detector Pos Peak Gated Sweep Off
Display line Off Gate Delay 12 μs
Video bandwidth 3 MHz(Auto) Gate Length 84 μs
VBW/RBW ratio 1.000 (Auto) Gate Source External
Resolution
bandwidth
3 MHz(Auto) Sweep Time Rule Speed
