133
Key Reference
MODE
Power Meter
Press Mode > Power Meter to access the optional power meter
functions. When this mode is selected, the power meter
related softkey menu will be displayed and many of the
instrument hardkeys will be disabled as they are not
necessary for this mode.
Mode toggles the measurement between AVG and Peak. When it is
set to AVG, the result showned in screen is the power
sensor’s measurement result. When it is set to Peak, the
result shown in screen is the power sensor’s gate
measurement result.
Key access: Mode > Power Meter
Zeroing Accesses the associated Zeroing submenu.
Key access: Mode > Power Meter
Zeroing Makes a Zero operation of the power sensor.
The U2000 Series USB Power Sensors have their
sensor calibration tables stored in non- volatile
memory which means that the reference
calibration factor is automatically loaded upon
power- up.
Key access: Mode > Power Meter > Zero/Cal
