Keysight Technologies N9322C - Front Panel Overview

Overview
Front Panel Overview
4
Front Panel Overview
1Screen 6.5 inch TFT color screen shows information of the
current function, including the signal traces, status
indicators, and instrument messages. Labels for softkeys are
located on the right- hand side of the screen.
2Softkeys are the unlabeled keys next to the screen. They
activate functions displayed to the left of each key.
3 Amplitude activates the reference level function and
accesses the amplitude softkeys, with which you set
functions that affect data on the vertical axis.
4SPAN sets the frequency range symmetrically about the
center frequency. The frequency- span readout describes the
total displayed frequency range.
5Frequency activates the center- frequency function, and
accesses the menu of frequency functions.
6 Function Keys relate directly to the following main functions:
• BW activates the resolution bandwidth function and
accesses the softkeys that control the bandwidth functions
and averaging.
• Trace/Det accesses the softkeys that allow you to set up
the trace settings and detector functions.
STU
VWX
YZ_
PROBE POW ER
RF IN 50
TG SOURCE CAL OUT
40MHz 25dBm
Rem ot e
Sta ndby
On
7
·
4
1
0
2
5
9
6
3
Frequency
Span
Marker
Lim it
Save
BW Trace/
MeasMode
Preset
Amplitude
Ent er
Sweep
8
N9322C 9kHz - 7.0 GHz
Spectrum Analayzer
File
Local
Disp
UserDet
Peak
Search
System
ESC
ABC
DEF
GHI
JKL
MNO
PQR
Rev Pw r 50VDC Max
+30dBm (1W ) Max
50VDC Max
33dBm (2W) Max
Shift
1
9
10
11
12
13
19
18
17
16
15
8
5
6
4
3
2
14
7
