3
Overview
N9322C at a Glance
• Modulation Analysis Function
provides optional AM/FM and ASK/FSK modulation analysis
function. (AM/FM: Option- AMA ASK/FSK: Option- DMA)
• Tracking Generator (Option TG7)
provides an RF source for scalar network analysis.
• Baseband Channel (Option BB1)
Provides superior DANL and SSB between 9 kHz to 10 MHz.
• Cable & Antenna Test (Option RM7; Requires option TG7)
Provides VSWR, return loss, cable loss and distance- to- fault
function for reflection measurement.
• Task Planner (Option TPN)
Provides task planner function to integrate different
measurements for test automation.
• Time-gated Spectrum Analysis (Option TMG)
Measures any one of several signals separated in time and
xxclude interfering signals.
• Channel Scanner (Option SCN)
provide the channel scan funtion in spectrum monitoring,
coverage test, and band clearance.
Optimized Usability
The analyzer provides the enhanced usability as below:
• Socket/Telnet remote control via USB, and LAN port.
• The BSA PC Software on help kit CD provides further editing
and data analysis functions.
• Keypad can be locked and unlocked with password to
forbid undesired keypad operation.
• The GPIB interface (option G01) make the unit easily
compatible with your GPIB test system.
• Security feartures (Option SEC) allows user to erase all
customized files and data in analyzer for security.
