Overview
Front Panel Overview
8
13 Softkey menu Refer to “Key Reference” for details.
Dependent on current function key selection.
14 Frequency span [SPAN]
15 Sweep time [Sweep] > Sweep Time
16 Fequency offset [Frequency] > Freq Offset
17 Video bandwidth [BW] > Video BW
18 Display status line Display status and instrument messages.
19 Resolution bandwidth [BW] > Res BW
20 Center Frequency [Frequency] > Center Freq
21 Active function block The functino in use
22 Low frequency channel [Frequency] > LowFrqChannel
23 Sweep time rule [Sweep] > Sweep Setup > Swp Time Rule
24 Sweep type [Sweep] > Sweep Setup > Sweep Type
25 - right Trigger/Sweep
F - free run trigger
V - video trigger
E - external trigger
C - continuous sweep
S - single sweep
[Sweep] > Trigge
25 - left Internal preamp [Amplitude] > Int Preamp
26 Trace mode
W - clear write
M - maximum hold
m - minimum hold
V - view
S - store blank
[Trace]
Detect mode
N - Normal
A - Average
P - Positive peak
S - Sample
N - Neg Peak
[Trace] > Detector
