Key Reference
Sweep
156
In zero span
Auto- coupled does not function when in a zero span. The
sweep time can only be set manually. The sweep time is
selectable from 6 s to 200 s in zero span.
In FFT Mode
In FFT mode, the sweep time default is auto- coupled. The
submenu, sweep time is invalid in FFT mode.
Key access: Sweep
Sweep
Single Cont
Pressing Sweep Single puts the analyzer in single- sweep
mode. Press Sweep Single to initiate a sweep when in
single- sweep mode. Press Sweep Cont Performs one sweep
after another as soon as it is triggered. Pressing Preset
(When Preset Type is set to Factory) sets the sweep mode to
continuous sweep.
Key access: Sweep
Single Sweep When the analyzer is in continuous sweep mode and not in
a measurement mode (MEAS > Measure Off), pressing Sweep >
Single Sweep will change the sweep setting to single sweep. It
will then begin a sweep after the trigger conditions are met.
If the analyzer is already in single sweep, pressing Sweep >
Single Sweep will execute a new sweep as soon as the trigger
condition is met.
If average is on (TRACE > More > Average Number On), pressing
Sweep > Single Sweep will halt averaging of the current value,
and then continue averaging from the current count number
when a single sweep function triggers.
Key access: Sweep
