Keysight N774xC Series Multiport Power Meter Programming Guide 35
Instrument Setup and Status 3
Response: The sum of the results for the individual Channels (a 16-bit unsigned integer value, where 0 ≤ value ≤ 65535):
Bits Mnemonics Decimal Value
N7744C N7745C
9-15 Not used Not used
8 Not used Channel 8 Summary 256
7 Not used Channel 7 Summary 128
6 Not used Channel 6 Summary 64
5 Not used Channel 5 Summary 32
4 Channel 4 Summary Channel 4 Summary 16
3 Channel 3 Summary Channel 3 Summary 8
2 Channel 2 Summary Channel 2 Summary 4
1 Channel 1 Summary Channel 1 Summary 2
0 Not used Not used 1
Example: :stat:oper:cond? -> +0
Command: :STATus:OPERation:ENABle
Syntax: :STATus:OPERation:ENABle<wsp><value>
Description: Sets the bits in the Operational Status Enable Summary Mask (OSESM) that enable the contents of the OSESR to affect the
Status Byte (STB).
Setting a bit in this register to 1 enables the corresponding bit in the OSESR to affect bit 7 of the Status Byte.
Parameters: The bit value for the OSESM as a 16-bit unsigned integer value (0 .. +65535)
The default value is 65535.
Response: none
Example: :stat:oper:enab 128
Command: :STATus:OPERation:ENABle?
Syntax: :STATus:OPERation:ENABle?
Description: Returns the OSESM for the OSESR
