90 Keysight N774xC Series Multiport Power Meter Programming Guide
4 Measurement Operations & Settings
Triggering - The TRIGger Subsystem
The TRIGger Subsystem allows you to configure how the instrument reacts
to incoming or outgoing triggers.
Command: :TRIGger
Syntax: :TRIGger<wsp>NODEA|1|NODEB|2
Description: Generates a hardware trigger.
Parameters: 1 or NODEA:
2 or NODEB:
Is identical to a trigger at the Input Trigger Connector.
Generates trigger at the Output Trigger Connector.
A hardware trigger cannot be effective in the DISabled triggering mode but can be effective in DEFault, PASSthrough or
LOOPback triggering modes, see :TRIGger:CONFiguration on page 94 for information on triggering modes.
Response: None
Example: :trig 1
Command: :TRIGger[n]:DELay?
Syntax: :TRIGger[n]:DELay?
Description: Returns factor for delay. Effective trigger delay time = factor/32 Mhz
Parameters: None
Response: Factor
Example: :trig1:del? → +0
Command: :TRIGger[n]:DELay
Syntax: :TRIGger[n]:DELay<wsp><value>
Description: Defines factor for delay. Effective trigger delay time = factor/32 Mhz. That means, trigger event is excuted after specified
time after input trigger.
