Keysight NFA Series Noise Figure Analyzers Service Guide 29
Overview
Service Equipment You Will Need
Attenuators
10 dB
Step Attenuator
Range: 0 to 80 dB
Accuracy:
Characterized by standards lab
f
Calibrated at 50 MHz
VSWR: at 50 MHz: ≤ 1.05:1
8496G
(Option 001,
H50)
8496H
(Option 001, H50)
P
1dB
Step Attenuator
Range: 0 to 9 dB
Accuracy:
Characterized by standards lab
f
VSWR: at 50 MHz: ≤ 1.05:1
8494G
(Option 001,
H50)
8494H
(Option 001, H50)
P
Attenuator
Interconnect Kit
Type N connector kit to connect 8496G to
8494G
11716A P
Attenuator Driver Compatible with the 8496G and 8494G step
attenuators
11713B 11713A P
3dB
Fixed Attenuator
Frequency: 50 MHz
Loss: 3 dB (nominal)
VSWR: at 50 MHz: ≤ 1.2:1
Connector: Type-N (m, f)
8491A
(Option 003)
8491B
(Option 003)
P
6dB
Fixed Attenuator
Frequency: 50 MHz
Loss: 6 dB (nominal)
VSWR: at 50 MHz: ≤ 1.05:1
Connector: Type-N (m, f)
8491A
(Option 006,
H33
g
)
8491B
(Option 006,
H33
g
)
P
6dB
Fixed Attenuator
(2 required)
Frequency: 50 MHz to 3.6 GHz
Loss: 6 dB (nominal)
VSWR: at 50 MHz: ≤ 1.10:1
Connector: 3.5 mm (m, f)
8493C
(Option 006)
A
10 dB
Fixed Attenuator
Frequency: 50 MHz
Loss: 10 dB (nominal)
VSWR: at 50 MHz: ≤ 1.05:1
Connector: Type-N (m, f)
8491A
(Option 010,
H33
g
)
8491B
(Option 010,
H33
g
)
P
10 dB
Fixed Attenuator
Frequency: 50 MHz to 19.5 GHz
Loss: 10 dB (nominal)
VSWR:
321.4 MHz to 8 GHz: ≤ 1.1:1
8 GHz to 12.4 GHz: ≤ 1.15:1
12.4 GHz to 19.5 GHz: ≤ 1.25:1
Connector: 3.5 mm (m, f)
8493C
(Option 010)
A, P
20 dB
Fixed Attenuator
Frequency: 10 MHz
Loss: 20 dB (nominal)
VSWR: 10 MHz: ≤ 1.20:1
Connector: Type-N (m, f)
8491A
(Option 020)
8491B
(Option 020)
A, P
Table 1-1 Required Test Equipment
Instrument Critical Specifications Recommended
Model
a
Alternative
Model
Use
b
