Keysight N8973B User Manual

Keysight NFA Series Noise Figure Analyzers Service Guide 361
Replaceable Parts
Replaceable Parts
Table 14-2 Attaching Hard ware
Attach To Qty Part Number Type Tool Torque
Analog IF Digital IF 3 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Analog IF (Top Shield) Analog IF (Bottom
Shield)
16 0515-0664 M3 X 0.5
(12 mm long)
Torx T-10 9 inch-lbs
Attenuators Attenuator Bracket 2 per 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Attenuators Chassis 2 per 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Bail Handle Front Frame 4 0515-0435 M4 X 0.7
(14 mm long)
Torx T-20 21 inch-lbs
Bandpass Filter Bandpass Filter Spacer 3 0515-0661 M2 X 0.4
(6 mm long)
Torx T-6 3 inch-lbs
Bandpass Filter Spacer RF Front End Assembly 4 0515-0658 M2 X 0.4
(6 mm long)
Torx T-6 3 inch-lbs
Chassis Bottom Chassis Sides,
Midplane
& Front Bracket
15 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Chassis Side
(Right Outside)
Low Band Switch
Bracket, Attenuator
Brackets, Chassis
bottom
7 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
CPU Assembly Chassis 6 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
CPU Shield CPU & Hard Disk Drive 19 0515-5074 M3 X 0.5
(6 mm long)
Torx T-10 9 inch-lbs
CPU Shield CPU Assembly 3 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
19 0515-1946 M3 X 0.5
(6 mm long)
Torx T-10 9 inch-lbs
Digital IF LVDS Connector 2 0515-4439 M2.5 X 6.0 Small Pozi 5 inch-lbs
Display Display Bracket 4 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Display Display Bracket 4 0515-1934 M2.5 X 0.45
(6 mm long)
Torx T-8 5 inch-lbs
Display Bracket & Front
Panel
Interface/Speaker
Bracket
Front Frame 7 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
