362 Keysight NFA Series Noise Figure Analyzers Service Guide
Replaceable Parts
Replaceable Parts
Disk Drive Disk Drive Tray 4 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Disk Drive Interconnect CPU Assembly 2 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Disk Drive Handle Disk Drive Rear Panel 2 0515-1946 M3 X 0.5
(6 mm long)
Torx T-10 9 inch-lbs
Disk Drive Rear Panel Disk Drive Tray 4 0515-2219 M2.5 X 0.45
(5 mm long)
Torx T-8 9 inch-lbs
External Reference
BNC
Rear Panel 1 2190-0102 Lock Washer n/a n/a
External Reference
BNC
Rear Panel 1 0590-2332 Hex Nut 9/16” Nut
Driver
21 inch-lbs
Fan Assembly Chassis 5 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Fan Fan Bracket 8 0361-1272 Rivets n/a n/a
Front Bumpers
(Opt. PRC)
Front Frame 8 0515-0435 M4 X 0.7
(14 mm long)
Torx T-20 21 inch-lbs
Front Chassis Bracket
& Midplane Bracket
Chassis Sides 10 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Front Frame Chassis 8 0515-2032 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Front Frame Bottom Chassis 2 per 0515-2032 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Front Panel Assy. Chassis 6 0515-2032 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Front Panel Daughter
Board
Front Frame 3 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Front Panel Interface Front Frame 13 0515-1521 M3 X 0.5
(5 mm long)
Torx T-10 9 inch lbs.
Low Band Switch Assy. Chassis 2 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Low Band Switch Assy. Low Band Switch
Bracket
4 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Midplane Assembly Midplane Bracket 6 0515-0375 M3 X 0.5
(16 mm long)
Torx T-10 9 inch-lbs
Motherboard Chassis Base 4 0515-0372 M3 X0.5
(8 mm long)
Torx T-10 9 inch-lbs
Table 14-2 Attaching Hard ware
Attach To Qty Part Number Type Tool Torque
