115
4
4
Features of your vehicle Automatic climate control system
Mode selection
The mode selection button controls the
direction of the air flow through the ven
-
tilation system.
The air flow outlet ports are switched in
the following sequence:
Face-Level (B, D, F)
Air flow is directed toward the upper
body and face. Additionally, each outlet
can be controlled to direct the air dis
-
charged from the outlet.
Bi-Level (B, C, D, E, F)
Air flow is directed towards the face and
the floor.
Floor-Level (A, C, D, E, F)
Most of the air flow is directed to the
floor, with a small amount of the air
being directed to the windshield, side
window defrosters and side air vents.
Floor/Defrost-Level (A, C, D, E, F)
Most of the air flow is directed to the
floor and the windshield with a small
amount directed to the side window
defrosters and side air vents.
Defrost-Level (A, D)
Most of the air flow is directed to the
windshield with a small amount of air
directed to the side window defrosters
and side air vents.
Instrument panel vents
Front
Rear (if equipped)
You can adjust the direction of air deliv
-
ered from these vents using the vent
control lever as shown. If you do not
want the air delivered, place the vent
control lever to the close position.
ODL3A040313
ODL3A041341
ODL3A040086
