Maintenance Fuses
BRAKE SWITCH 10A IBU (Integrated Body Control Unit), Stop Lamp Switch
SUNROOF2 20A Sunroof Controller (Blind Motor), Data Link Connector
AIR BAG2 10A SRS (Supplemental Restraint System) Control Module
AIR BAG1 15A SRS (Supplemental Restraint System) Control Module
MEMORY 10A
Head-up Display, Driver IMS (Integrated memory system) Module, Driver/Passenger Power
Outside Mirror, Rain Sensor, Instrument Cluster, Air Conditioner Control Module, Air Condi
-
tioner Switch
MULTI MEDIA 15A DC-DC Converter (Audio), Audio, Audio/Video & Navigation Head Unit
SUNROOF1 20A Sunroof Controller (Glass Motor)
MODULE7 10A
4WD (4 Wheel Drive) ECU (Engine Control Unit), Front Console Switch #1/#2, Front View
Camera, IBU (Integrated Body Control Unit), Crash Pad Switch, ADAS Parking ECU, EPB
Switch, Vacuum Switch
MDOULE5 10A Stop Lamp Switch
MODULE8 10A
AMP (Amplifier), Driver IMS (Integrated memory system) Module, Front Wireless Charger,
Front Air Ventilation Seat Control Module, Front/Rear Seat Warmer Control Module, ATM
(Automatic Transmission) Shift Lever Indicator, Data Link Connector, Audio, Audio/Video &
Navigation Head Unit, Air Conditioner Switch, Surround View Monitor Unit, Air Conditioner
Control Module, DC-DC Converter (Audio/AMP (Amplifier)), Electro Chromic Mirror
MODULE2 10A
Cooling Fan Motor, ADAS Parking ECU, Front/Rear Seat Warmer Control Module, Front Air
Ventilation Seat Control Module, Engine Room Junction Block (W/S Heated Glass Left Handle
side/Right Handle side Relay)
MDPS 7.5A MDPS (Motor Driven Power Steering) Unit (Column Type, Rack Type)
A/C1 7.5A
Air Conditioner Control Module, Air Conditioner Switch, Engine Room Junction Block (Blower
Relay)
MODULE4 10A
Rear USB Charger, PCB Block (Power Outlet Relay), Console USB Charger (Outside Rear Left
Handle side/Right Handle side), Console USB Charger (Inside), AMP (Amplifier), IBU (Inte
-
grated Body Control Unit), DC-DC Converter (Audio/AMP (Amplifier)), Audio, Audio/Video &
Navigation Head Unit, Surround View Monitor Unit, ADAS Parking ECU
MODULE9 7.5A IBU (Integrated Body Control Unit)
CLUSTER 10A Instrument Cluster, Head-up Display
WASHER 15A Multifunction Switch
START 7.5A
B/Alarm Relay, IBU (Integrated Body Control Unit), ECM (Engine Control Module), Transmis
-
sion Range Switch, Engine Room Junction Block (Start Relay)
POWER OUTLET 20A Not Used
IBU2 7.5A IBU (Integrated Body Control Unit)
A/BAG IND 7.5A Instrument Cluster, Overhead Console Lamp
SPARE2 10A Not Used
A/C2 10A Air Conditioner Control Module
Fuse Name Fuse rating Circuit Protected
