Now place the thin piece of foam with the hole and the slot over the
EpiSensor placing the connector through the hole. This is shown in Figure
7 below.
Figure 7: Second Packaging Piece Installed over Connector Shell
Finally the last piece of packaging can be placed over the connector and
cable as shown below in Figure 8. If this is done we recommend using
aluminum duct tape to hold the packing together and also ensuring a joint
with the floor to minimize convection currents.
