DOCUMENT 301900, REVISION D
EPISENSOR USER GUIDE 55
With the parts you need pulled out of the kit and the proper width of tape
prepared, begin assembling the recorder-end mating connector.
1. Strip off 3/4" of the outer black rubber tubing on one end of the
Shrink-N-Shield tubing (shown on the right side of Figure 24).
While stripping this off, be careful not to nick the remaining tubing
or the cloth/screen mesh.
2. Gather the parts listed in Table 13 and slide them a couple of feet
up over the cable’s outer jacket so they are out of the way until
needed. Slide them over the jacket in the listed order, top to
bottom. If you are not sure which pieces of the connector to use,
see Figures 24 -26 to help identify the correct parts.
Table 13: Part order, recorder cable end
Part Name KMI P/N
Thermofit tubing 851186
Connector strain relief grommet Part of 851119
Connector back shell Part of 851119
Shrink-n-Shield tubing 850839
Connector’s plastic grommet ring Part of 851119
Cable Assembly Instructions
! When the recorder end of the cable is attached, proceed to the
Initial Assembly of the EpiSensor End section on page 2-17.
! When that is done, return to this section and repeat the Identical
Assembly Procedures for the EpiSensor below.
! To finish the cable, go to the instructions in the Final Assembly of
the EpiSensor End on page 2-19.
Identical Assembly Procedures
The following assembly procedures and illustrations are exactly the same
for both ends of the cable through the end of this section.
Complete these identical procedures on both ends of the cable.
1. Using a utility knife, strip and remove 2" of the cable’s outer PVC
jacket.
2. Fold back the cellophane and white string covering the shielded
wires.
