DOCUMENT 301900, REVISION D
EPISENSOR USER GUIDE 53
Initial Assembly of the Altus Recorder End
To assemble the recorder-end of the 840356 cable, open the assembly kit
and pick out the parts listed in Table 12 and illustrated left-to-right in Figure
22. Keep the other parts in the assembly kit bag; you will need them later.
To install mating connector P/N 851119, you require the following:
Table 12: Parts for recorder mating connector assembly
Part Name KMI P/N Commercial P/N Description of Item/s
Mating connector 851119 851-06EC14-19PN50 1 connector
Foil tape 880699 1183 (3/8" wide) 6 pieces, 3/8" x 1"
Foil tape 880699 1183 (3/8" wide) 1 piece, 3/8" x 3"
Foil tape 880700 1183 (1" wide) 1 piece, 1" x 3"
Shrink tubing 850839 FIT 221-1/4" 1 piece, cut 1/4" long
Shrink-n-Shield tubing 851366 SST-20 1 piece, 3" long
Thermofit tubing 851186 DWP-125 3/4-black 1 piece, 3/4" long
Required tools and supplies:
! Soldering iron (approx. 50 watts)
! Solder
! Wire cutters
! Wire strippers
! PVC insulating tape
! Utility knife
! Heat gun
! 3½-digit DVM with 200 ohm range or equivalent
Caution: Be careful when working with the foil tape – it is very sharp.
