Accessing Vision module color and depth streams
This section describes access to the video module color and depth streams.
The video module sensors capture two video streams:
• color
• depth
The data from these streams is sent from the vision module back to the base controller via the
vision / expansion channel carried over the internal flex cable links.
These two streams are accessible via the Real Time Streaming Protocol (RTSP) on a computer
connected to the robot (with transport over real-time transport protocol (RTP)).
Using the default IP address settings for the base controller, the two streams are accessible via:
• color sensor stream: rtsp://<base IPv4 address>/color
• depth sensor stream: rtsp://<base IPv4 address>/depth
For the default configuration of the base controller network interface, this would give:
• rtsp://192.168.1.10/color
• rtsp://192.168.1.10/depth
Note: Examples in the documentation will use the default base controller IP setting for
simplicity.
Streams specifications
• pixel format: Z16 pixel format - 16 bits LSB transferred as grayscale
• H.264 baseline profile (constant bitrate)
• RTSP server listening on port 554 (default)
• maximum of two simultaneous connections per stream
• inactivity timeout of 30 seconds
The KINOVA
®
KORTEX™ Developer Guide section of the user guide describes in more detail
how to work with the vision module camera streams.
